Specificaties

FRAME M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
SEAT BINDER Alloy, 38.6mm
REAR SHOCK X-Fusion 02 Pro RL, Ride Dynamics Trail Tune, rebound adjust, lockout S1:210x52.5mm, S2-S6:210x55mm
FORK RockShox, Psylo Silver, Motion Control Damper, 15x110 axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
FRONT BRAKE Shimano, BR-MT420, 4-piston caliper, hydraulic disc, 203mm
REAR BRAKE Shimano, BR-MT420, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 203mm
SHIFT LEVERS Shimano Deore, M6100, 12spd
REAR DERAILLEUR Shimano Deore, M6100, 12pd, Shadow Plus
CASSETTE Shimano Deore M6100, 12spd w/Hyperglide+, 10-51t
CHAIN Shimano Deore, M6100, 12-speed
CRANKSET Shimano Deore, M6120, 30T ring, 55mm chainline, S1-S3:165mm, S4-S6: 170mm
RIMS Specialized Alloy, Tubeless Ready, 29mm internal width, 28h, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
FRONT HUB Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
REAR HUB Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES Stainless, 14g
FRONT TIRE Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
REAR TIRE Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
INNER TUBES Standard, Presta valve
STEM Alloy Trail Stem, 35mm bar bore
HANDLEBARS Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise; S3-S4: 800 width, 30mm rise; S5-S6: 800 width, 40mm rise
GRIPS Specialized Trail Grips
SADDLE Bridge, Steel rails, S1-S2: 155mm, S3-S6: 143mm
SEATPOST TranzX Dropper, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 200mm
SWAT SWAT internal downtube storage

Publicatiefouten voorbehouden. Specificaties kunnen zonder voorafgaande kennisgeving worden gewijzigd.
